HD-300A (6 colors) full-automatic trademark rotary printing machine
Keyword: HD-300A (6 colors) full-automatic trademark rotary printing machine
Product Details
Features:
1. Imported servo system, flexible motion control.
2. Computer-controlled ink supply system, stable and accurate ink transfer.
3. Maximum intermittent printing area of 290mm * 280mm.
4. Refresh high-speed and precise time position, no displacements of acceleration or deceleration, good stability.
5. Low-backlash high-precision gears, smooth high-speed operation, low noise.
6. The UV dryer lamp holder can realize automatic power switching to achieve the effect that the paper does not deform at low temperatures and the ink is completely dry.
7. High-speed color code electric eye alignment, to ensure high-quality secondary overprint, and reduce material waste.
8. Direct sleeve position adjustment through man-machine dialogue, to achieve easier and more accurate operation.
9. The printing tension can be adjusted freely according to the printing materials.
10. Isolated power supply mode, more energy saving under the same conditions.
11. The introduction of foreign advanced shaftless printing control technology.
12. Can be equipped with varnish seats, magnetic circular cutter die-cutting seats, etc., widely used in food, cosmetic, medicine, electrical appliances, electronics, mobile phone laminating, hardware, toys, gifts and other industries.
| Model | Paper Width | Maximum Printing Area Of Rotation | Intermittent Maximum Printing Area | Printing Speed |
UV Dryer |
| HD-300 | 300mm | 290mm*326mm |
MAX 290mm*280mm MIN 70mm*31mm |
12000/H |
（1-5）3.6KW （ 6 ）4.8KW |
| Mechanical Dimensions | Mechanical Weight |
Host Power |
|||
| 7600mm*1620mm*1480mm | 5400KG | 22KW |
